Product Description
727264-5001S
140-230hp capability
Displacement range: 1.4L to 2.0L
Internally wastegated. Includes wastegate actuator
Sold as Complete Turbo
Compressor Specs
-0.51 A/R compressor housing 2.12" inlet 1.96" outlet
-52-trim compressor wheel 1.48/2.05 37.6mm inducer (727264-1)
Turbine Specs
-0.50 A/R turbine housing internally wastegated, 4-bolt inlet
-47.0mm 72-trim GT20 turbine wheel
CHRA Specs
-Oil-cooled bearing housing
-Dry bearing housing (non-water cooled)
Part Numbers
727264-1 - Complete Turbo 0.50 A/R turbine, 52-trim, 37.6mm compressor
